HOW TO configure vnc server and client on linux machine

Dear All,

This is one of the common task DBA needs to do :

1. HOW TO access linux server from windows machine remotely?

2. HOW TO configure vnc server on linux machine

Answer of question 1,2:

Step:

1. Download and install vnc client version on windows machine here

2. logon to linux machine with root

3. check vnc rpm required package is installed or not

4. add a user to vnc server file

5. setting password for vnc access

6. start vnc server

login as: root

root@192.168.100.9's password:

Last login: Sun Sep 25 12:29:14 2011 from 192.168.104.114

[root@fakorapd ~]# rpm -qa | grep vnc

vnc-server-4.1.2-9.el5

[root@fakorapd ~]# cat /etc/sysconfig/vncservers

# The VNCSERVERS variable is a list of display:user pairs.

#

# Uncomment the lines below to start a VNC server on display :2

# as my 'myusername' (adjust this to your own).  You will also

# need to set a VNC password; run 'man vncpasswd' to see how

# to do that.

#

# DO NOT RUN THIS SERVICE if your local area network is

# untrusted!  For a secure way of using VNC, see

# .

# Use "-nolisten tcp" to prevent X connections to your VNC server via TCP.

# Use "-nohttpd" to prevent web-based VNC clients connecting.

# Use "-localhost" to prevent remote VNC clients connecting except when

# doing so through a secure tunnel.  See the "-via" option in the

# `man vncviewer' manual page.

# VNCSERVERS="2:myusername"

# VNCSERVERARGS[2]="-geometry 800x600 -nolisten tcp -nohttpd -localhost"

[root@fakorapd ~]# vi /etc/sysconfig/vncservers

[root@fakorapd ~]# vncpasswd

Password:

Verify:

[root@fakorapd ~]# vncserver :1

xauth:  creating new authority file /root/.Xauthority

New 'fakorapd.fakhruddin.local:1 (root)' desktop is fakorapd.fakhruddin.local:1

Creating default startup script /root/.vnc/xstartup

Starting applications specified in /root/.vnc/xstartup

Log file is /root/.vnc/fakorapd.fakhruddin.local:1.log

[root@fakorapd ~]# cd

[root@fakorapd ~]# cd .vnc/

[root@fakorapd .vnc]# cat xstartup

#!/bin/sh

# Uncomment the following two lines for normal desktop:

# unset SESSION_MANAGER

# exec /etc/X11/xinit/xinitrc

[ -x /etc/vnc/xstartup ] && exec /etc/vnc/xstartup

[ -r $HOME/.Xresources ] && xrdb $HOME/.Xresources

xsetroot -solid grey

vncconfig -iconic &

xterm -geometry 80x24+10+10 -ls -title "$VNCDESKTOP Desktop" &

twm &

[root@fakorapd .vnc]# vi xstartup

[root@fakorapd .vnc]# vncserver -kill :1

Killing Xvnc process ID 9881

[root@fakorapd .vnc]# vncserver :1

New 'fakorapd.dummy.local:1 (root)' desktop is fakorapd.dummy.local:1

Starting applications specified in /root/.vnc/xstartup

Log file is /root/.vnc/fakorapd.dummy.local:1.log

[root@fakorapd .vnc]#

---you will see grey color screen but not colorful :) in linux server , because we have started xserver , comment out below lines from xstartup file---

[root@fakorapd ~]# cd .vnc/

[root@fakorapd .vnc]# cat xstartup

#!/bin/sh

# Uncomment the following two lines for normal desktop:

# unset SESSION_MANAGER

# exec /etc/X11/xinit/xinitrc

[ -x /etc/vnc/xstartup ] && exec /etc/vnc/xstartup

[ -r $HOME/.Xresources ] && xrdb $HOME/.Xresources

xsetroot -solid grey

vncconfig -iconic &

xterm -geometry 80x24+10+10 -ls -title "$VNCDESKTOP Desktop" &

twm &

[root@fakorapd .vnc]# vi xstartup

[root@fakorapd .vnc]# vncserver -kill :1

Killing Xvnc process ID 9881

[root@fakorapd .vnc]# vncserver :1

New 'fakorapd.dummy.local:1 (root)' desktop is fakorapd.dummy.local:1

Starting applications specified in /root/.vnc/xstartup

Log file is /root/.vnc/fakorapd.dummy.local:1.log

after that you will be able to see color ful desktop of linux server as below.

Reference: http://bobpeers.com/linux/vnc
